TM1700P
17″ Industrial True-flat PCAP Touch Monitor
Data sheet (PDF)| Front Bezel | Ultra slim aluminum front bezel |
| LCD Panel | 17" |
| Max Colors | 16.7 M |
| Active Area | 337.92 x 270.336 (mm) |
| Max Resolution | 1280 x 1024 |
| Display Mode | VGA x 1, DP x 1, HDMI x 1 VGA x 1, DVI x 1 (Optional) |
| Pixel Pitch | 0.264 x 0.264 (mm) |
| Backlight MTBF | 50,000 Hrs |
| Viewing Angle | 88/88 (H), 85/85 (V) |
| Response Time | |
| Contrast Ratio | 1000 : 1 |
| LCD Brightness | 250 Nits |
| Display Control | OSD Key Control |
| I/O Interface | - VGA x 1, DP x 1, HDMI x 1 - VGA x 1, DVI x 1 (Optional) - Ambient light sensor (Optional) |
| Touch Screen | True-flat PCAP Touch (USB Interface) or Resistive Touch (Optional) |
| Power Adapter | Power supply DC 12V or Universal 90-240V, 12V/50W power adapter |
| Power Consumption | |
| Operating Temperature | 0°C ~ 60°C |
| Dimensions | 392.32 x 324.82 x 50 (mm) |
| Weight | 3.0 Kg |
| Mounting | VESA Mount 75 x 75 mm or 100 x 100 mm |
| Certifications | CE, FCC |
