MF-H410G-201
Embedded System with 10th Comet Lake-S Core i3/i5/i7 Processor
Data sheet (PDF)| CPU | Intel 10th Comet Lake-S LGA1200 Socket Processor TDP Max. 65W |
| Chipset | Intel H410 |
| System Memory | Dual Channel DDR4 2666/2933 MHz SO-DIMM, up to 32GB |
| BIOS | AMI |
| COM | 2 x RS-232 |
| USB | 4 x USB 3.0 |
| Ethernet | 2 x RJ-45, Intel I219V Giga LAN + Intel I211-AT Giga LAN |
| PoE | - |
| Display | 1 x HDMI 2.0 (Up to 3840 x 2160), 2 x HDMI 1.4 |
| Digital I/O | Programmable support 10-bit GPIO |
| Audio | 1 x Mic-in / 1 x Line-out |
| Storage | 2 x SATAIII |
| Expansion | 1 x Full size Mini-PCIe slot co-lay with mSATA |
| Others | 1 x I2C, 1 x SMBUS, 1 x SATA Power output |
| Power Supply | - |
| Watchdog Timer | 1 - 255 steps by software program |
| Construction | - |
| Operating Temperature | 0°C to +60°C (+32°F to +140°F) |
| Relative Humidity | 10% to 95% relative humidity, non-condensing |
| Vibration | - |
| Shock | - |
| Dimensions | 218 x 202 x 56 mm |
| Weight | 1.4 kg (barebone) |
| Certifications | CE, FCC |
| EOS Support | - |
| Software Support | Win10 IoT, Linux |
| Mounting | VESA mount, Wall mount |
